The Power Quality Expert Best Friends !

As a Power Quality Expert, who should you be close to professionally

As a Power Quality Expert, it is important to have the right contacts in order to get the right information to specify an effective solution.  Here are a few of you important contacts and a list of questions that you may want to ask.

Get in contact with your Customer process Suppliers

Source: www.idealformart.com

So you have to solve a Power Quality problem for a specific load, either a variable speed drive, soft start or a power controller.  Refine your detective skills! Identify exactly where the compatibility issues is by getting the alarm information or a particular mis-operation. Is the drive tripping on low voltage, high voltage, frequency variation or the power controller does not produce constant power output.

Contact the company’s application engineer to discuss the mis-operations, chances are that this is not a new problem and there are out of the box solutions like a specific power controller for the customer’s application or a new trip settings for the motor drive or soft-start.

Know your Utility Engineer

Source: www.eastcountymagazine.org

Once you have determined the problem and the solutions, you need some information from the Utility Engineer.

For a problem concerning sags, swells or short interruptions, here is a list of questions you may want to ask:

  • What is the protection philosophy and setting for the line supplying your customer?
  • Is there a reclosure scheme, if so, ask what are the settings, this can make a big difference on your solution spec and cost?
  • In case of a permanent fault on the utility side, how much time does it take to transfer to the back-up, is it automatic or manual?

For a flicker problem, you may want to know:

  • What is the fault level at point of common coupling?
  • Is it possible to rearrange the supply to get a higher short circuit level?
  • What are the recommended levels at point of common coupling?

For a harmonic problem, here are the relevant questions:

  • What is the harmonic impedance at point of common coupling?
  • Is there other harmonic producing loads on the same feeder?
  • What are the recommended levels at point of common coupling?

Get in contact with your Power Quality Equipment Suppliers

Source: urtechfriend-paperpresentations5.blogspot.com

Now you have found solutions, time to analyse them.  Why not use my free spreadsheet to compare and select the optimal one, Get it here.

Once you found the optimal solution, it’s time to specify it.  Contact the  Power Quality Equipment Supplier’s application engineer to get a typical specification and ask how to rate it and for any additional information



Please add your comments.
